交流电流

0~600.0 /1000A
±1.5%rdg±5dgt (50/60Hz)
±3.0%rdg±5dgt (40Hz~400Hz )

直流电流

0~600.0 /1000A
±1.5%rdg±5dgt

交流电压

6/60/600V(自动量程)
±1.3%rdg±4dgt (50/60Hz)
±3.0%rdg±5dgt(40Hz~400Hz )

直流电压

600m/6/60/600V(自动量程)
±1.0%rdg±3dgt

电阻

600/6k/60k/600k/6M/60M?1?7?1?7?1?7?1?7?1?7?1?7?1?7?1?7?1?7?1?7?1?7?1?7?1?7?1?7?1?7?1?7  (自动量程)

±1%rdg±5dgt(600~6M?1?7?1?7?1?7?1?7?1?7?1?7?1?7?1?7?1?7?1?7?1?7?1?7?1?7?1?7?1?7?1?7)    ±5%rdg±8dgt(60M?1?7?1?7?1?7?1?7?1?7?1?7?1?7?1?7?1?7?1?7?1?7?1?7?1?7?1?7?1?7?1?7)

导通蜂鸣

100?1?7?1?7?1?7?1?7?1?7?1?7?1?7?1?7?1?7?1?7?1?7?1?7?1?7?1?7?1?7?1?7以下时蜂鸣

频率/DUTY

10/100/1k/10kHz (自动量程) / 0.1~99.9%

导体直径

大Ø40mm

安全规格

IEC61010-1 CAT IV 600V污染度2    IEC61010-031  IEC61010-2-032   IEC61326

耐电压

6880V AC/ 5秒

电池

R03(1.5V)(AAA)×2

外形尺寸

254(L)×82(W)×36(D)mm

重量

约310g(含电池)

附件/可选件

7066(测试线)   9094(携带皮套)
R03×2 使用说明书 /可选件8008电流转换器（AC）
